MACO A-TS Automatic Latch 2 Hook Lock 16mm Faceplate
MACO A-TS Automatic Latch 2 Hook Lock 16mm Faceplate
By purchasing you are agreeing to our Terms of Sale.
Low stock: 2 left
Couldn't load pickup availability
Maco Z-TS cylinder operated keywind mechanism multipoint lock with two hooks, antilift and a 16mm flat faceplate. The full length is 2400mm and it has an 8mm single spindle latch and deadbolt gearbox with 92mm centres.
Available in a choice of backset sizes this lock can be cropped to size or extended as necessary.
Operation
Locking Method - Keywind - Closing the door makes it latch shut. To lock turn the key which operates the deadbolt and the locking points. To unlock turn the key in the opposite direction.
MACO A-TS Automatic Latch 2 Hook Lock 16mm Faceplate
Features
- 2 Hooks
- 92mm centres
- Latch & deadbolt gearbox
- 16mm faceplate
- Single spindle
- Door automatically locks at 3 points when closed
Categories
- Multi Point Locks
- Door
- Full Units
- Maco
Our MACO A-TS Automatic Latch 2 Hook Lock 16mm Faceplate from Maco is a quality tested product at a reasonably low price.
If you need any further information or are looking for an alternative size or similar item please contact us.
| Option Specifications | |
|---|---|
| Backset | 45mm, 35mm |
| Case Height | 202mm |
| Case Width | 63mm, 53mm |
| Centre Case | Latch & Deadbolt |
| Centres | 92mm |
| Faceplate Width | 16mm |
| Length | 1.4m |
| Locking Point Hooks | 2 |
| Pack Quantity | 1 |
| Spindle | Single |
| Product References | L38310, L38309 |
| Barcode References | 5056240170602, 5056240170596 |
| * Information above is accurate at the time of entry and may be subject to change at any time. | |
